From Concept to Documentation — in a Fraction of the Time.
Automate every critical step in electrical and data center design while minimizing errors and staying fully compliant.
Quick selection of the optimal cable and protective device
Integrated database of power cables
Simple and intuitive user interface
Minimizes the possibility of human error
Forget about time-consuming manual processes – eliminate:
- Cable selection using tables and manuals
- Unnecessary browsing through catalogs and searching for technical information
- Manual preparation of bills of quantities and technical documentation
- Repeating calculations every time an input parameter changes
Main Features
Supported
calculations/checks:
Ampacity
Voltage drop
Load flow
Short circuit & coordination
Infrastructure losses
Focus on professional engineering work and quality solutions
Instead of administrative and repetitive error-prone activities.
Fast generation of reports
Ready to be used in project documentation.
Automated generation of single line diagrams in Autodesk AutoCAD
Simply let Kabelator draw single line diagrams in AutoCAD for you. There is no need to manually copy the data to AutoCAD, no need to type the data, possibility of “copy-paste” typos is eliminated.
Results of all calculations are shown live within the model file after change of any input parameter.
There is no need to generate individual reports in order to check the accuracy of the technical solution. This way you can quickly try out a lot of configurations in a short time.
Automatic sizing according to industry standards
IEC 60909 Short-circuit currents in three-phase a.c. systems
IEC 60364 International standard for low-voltage electrical installations.
Support for Roxtec cable seals
Select the locations of the cable seals and let Kabelator automatically prepare all the input transit data for Roxtec Tranist Designer (RTD). There is no need to manually write the cable data in the RTD.
Intuitive MS Excel environment supported by a graphical user interface
Represents a familiar and comfortable environment for design engineers and owners of electrical infrastructure.
Easy creation of technically correct and standardized project documentation
Kabelator guides the user towards a technically correct solution.
English and Croatian language supported
Translate the entire project and user interface into another language with single click at any moment.
